5-SK005
Model
RAM Heavy Duty
Part No. 5-SK005
Outer Dia. ( A ) Ø35.2 ~ Ø35.0
Outer Dia. ( B )
Spline
Spec.
 Type Fillet Root Side Fit
No. of Teeth 22
Module 1
Pressure Angle 37.5°
Major Dia. Ø23.58 Max.
Minor Dia. Ø21.34 ~ Ø21.15
Over Pin Dia. Ø18.425
Pin Dia. Ø2.120
Length ( C )
Length ( D ) 75.50
Length ( E ) 20
Inner Dia. ( F ) Ø46.5 ~ Ø46.3
Outer Dia. ( G ) Ø50.8 ~ Ø50.6
Length ( H )
Length ( I )
Spline Length ( J ) 47.5 Min.
Length ( K )
Groove Width ( L )
Groove Dia. ( M ) Ø29.65
Length ( N )
 Plating Electroless Nickel Plating
Material Forging
Weight 0.321 kg
 Package Qty.
