5-SK008
Model
RAM Heavy Duty
Part No. 5-SK008
Outer Dia. ( A ) Ø40.3 ~ Ø40.1
Outer Dia. ( B )
Spline
Spec.
 Type Fillet Root Side Fit
No. of Teeth 28
Module 24 / 48
Pressure Angle 37.5°
Major Dia. Ø31.623 Max.
Minor Dia. Ø28.9306 ~ Ø28.8036
Over Pin Dia.
Pin Dia.
Length ( C ) 26.70
Length ( D ) 62.50
Length ( E ) 20.00
Inner Dia. ( F ) Ø55.5 ~ Ø55.3
Outer Dia. ( G ) Ø60.8 ~ Ø60.6
Length ( H ) 5
Length ( I )
Spline Length ( J )
Length ( K ) 36.70
Groove Width ( L )
Groove Dia. ( M )
Length ( N )
 Plating Electroless Nickel Plating
Material Forging
Weight 0.382 kg
